How to Model Value Objects With EF Core

Persist value objects in EF Core with a value conversion for a single column, a complex type for a group of values, or an owned type when you need entity-style mapping such as a separate table. Choose against your EF Core version and provider: optional complex properties and complex JSON support arrive in EF Core 10.

What Is a Value Object?

A value object is defined by its properties, not by an identity. Two Money objects with the same amount and currency are equal, regardless of where they exist in memory. If you're unsure whether something is a value object at all, start with entity vs value object.

public sealed record Money(decimal Amount, string Currency)
{
    public static Money Zero(string currency) => new(0, currency);

    public Money Add(Money other)
    {
        if (Currency != other.Currency)
            throw new InvalidOperationException("Cannot add different currencies");

        return new Money(Amount + other.Amount, Currency);
    }
}

This record demonstrates equality and arithmetic; it does not validate supported currencies or monetary precision. The mapping examples belong in DbContext.OnModelCreating, use Microsoft.EntityFrameworkCore, and assume a configured relational provider. Entity declarations show persistence-relevant properties; add your application's constructors and domain methods around them.

Choose one mapping per property; the following sections show alternatives rather than configurations to apply together.

Option 1: Owned Types

Owned types map a value object's properties as columns in the owning entity's table:

public class Order
{
    public Guid Id { get; private set; }
    public Money TotalAmount { get; private set; } = null!;
    public Address ShippingAddress { get; private set; } = null!;
}

public sealed record Address(
    string Street, string City, string State, string ZipCode, string Country);

Configuration

modelBuilder.Entity<Order>(builder =>
{
    builder.HasKey(o => o.Id);

    builder.OwnsOne(o => o.TotalAmount, money =>
    {
        money.Property(m => m.Amount)
            .HasColumnName("total_amount")
            .HasPrecision(18, 2);

        money.Property(m => m.Currency)
            .HasColumnName("total_currency")
            .HasMaxLength(3);
    });

    builder.Navigation(o => o.TotalAmount).IsRequired();

    builder.OwnsOne(o => o.ShippingAddress, address =>
    {
        address.Property(a => a.Street).HasColumnName("shipping_street");
        address.Property(a => a.City).HasColumnName("shipping_city");
        address.Property(a => a.State).HasColumnName("shipping_state");
        address.Property(a => a.ZipCode).HasColumnName("shipping_zip");
        address.Property(a => a.Country).HasColumnName("shipping_country");
    });
    builder.Navigation(o => o.ShippingAddress).IsRequired();
});

The value object's properties are flattened into the entity's table. Column types and generated DDL depend on your provider and configuration.

When to Use Owned Types

• Multi-property value objects like Address, Money, DateRange
• When you need to query individual properties
• When the value object should be nullable (the entire owned type can be null)

One gotcha: EF Core doesn't allow the same owned instance to be shared by two owners. Sharing it across ownership relationships can produce tracking warnings or save failures. Because value objects are immutable, the fix is cheap: create a new instance (or use a with expression on the record).

I go deeper on this strategy in Owned Types in EF Core.

Option 2: Complex Types (EF Core 8+)

Complex types map grouped values without introducing a hidden entity key. To replace the owned mapping in the first example, configure both complex properties:

modelBuilder.Entity<Order>(builder =>
{
    builder.ComplexProperty(o => o.ShippingAddress);
    builder.ComplexProperty(o => o.TotalAmount, money =>
    {
        money.Property(m => m.Amount)
            .HasColumnName("total_amount")
            .HasPrecision(18, 2);

        money.Property(m => m.Currency)
            .HasColumnName("total_currency")
            .HasMaxLength(3);
    });
});

Differences from owned types:

• EF Core 8 and 9 require non-null complex properties; EF Core 10 supports optional ones
• Complex types cannot contain navigation properties
• Complex types cannot be stored in a separate table
• Instances can be shared because EF does not track a separate identity for each value

For optional values, EF Core 10's complex-type support requires at least one required member to distinguish a missing value from an object whose members are all null. Nullable reference annotations alone produce compiler warnings; they do not add runtime null checks.

When to Use Complex Types

• Grouped values without independent identity
• Simple value objects without relationships
• Required values on EF Core 8/9, or required and optional values on EF Core 10

Option 3: Value Conversions

Value conversions map a single property to a column using a converter:

public sealed record Email
{
    public string Value { get; }

    public Email(string value)
    {
        if (string.IsNullOrWhiteSpace(value) || !value.Contains('@'))
            throw new ArgumentException("Invalid email", nameof(value));

        Value = value;
    }
}

The email check is deliberately minimal; it demonstrates where validation belongs, not a complete address-validation policy. It does not prove that a mailbox exists.

Configuration

modelBuilder.Entity<Customer>(builder =>
{
    builder.Property(c => c.Email)
        .HasConversion(
            email => email.Value,                  // To database
            value => new Email(value))             // From database
        .HasMaxLength(256);
});

Or define an EF Core ValueConverter class:

using Microsoft.EntityFrameworkCore.Storage.ValueConversion;

public class EmailConverter : ValueConverter<Email, string>
{
    public EmailConverter()
        : base(
            email => email.Value,
            value => new Email(value))
    {
    }
}

// Registration
modelBuilder.Entity<Customer>(builder =>
{
    builder.Property(c => c.Email)
        .HasConversion<EmailConverter>()
        .HasMaxLength(256);
});

Apply Globally

protected override void ConfigureConventions(
    ModelConfigurationBuilder configurationBuilder)
{
    configurationBuilder
        .Properties<Email>()
        .HaveConversion<EmailConverter>()
        .HaveMaxLength(256);
}

Now every Email property in every entity uses the converter automatically.

When to Use Value Conversions

• Single-property value objects like Email, PhoneNumber, CustomerId
• Strongly typed IDs
• Enum-like value objects

Comparison

A value converter can serialize multiple values into one column, but EF cannot translate member access inside that converted object. For example, compare customer.Email == email; do not expect customer.Email.Value.EndsWith(...) to become SQL. Mutable wrappers may also need a value comparer; the immutable Email record already supplies value equality.

Collections of Value Objects

For a collection stored in a separate table, use OwnsMany. This Order declaration replaces the earlier mapping-only example:

public class Order
{
    public Guid Id { get; private set; }
    public IReadOnlyList<LineItem> LineItems => _lineItems.AsReadOnly();
    private readonly List<LineItem> _lineItems = new();
}

public sealed record LineItem(Guid ProductId, int Quantity, decimal UnitPrice);

modelBuilder.Entity<Order>(builder =>
{
    builder.OwnsMany(o => o.LineItems, lineItem =>
    {
        lineItem.ToTable("order_line_items");
        lineItem.WithOwner().HasForeignKey("OrderId");
        lineItem.Property<Guid>("Id").ValueGeneratedOnAdd();
        lineItem.HasKey("OrderId", "Id");
        lineItem.Property(li => li.UnitPrice).HasPrecision(18, 2);
    });
});

The shadow GUID key identifies each stored row without adding business identity to LineItem. EF generates that key on the client; this also avoids relying on an auto-incrementing integer inside a composite key, which SQLite does not support.

Alternatively, use owned JSON mapping on a provider that supports it. SQL Server added this support in EF Core 7; SQLite followed in EF Core 8. Replace the separate-table configuration with:

modelBuilder.Entity<Order>(builder =>
{
    builder.OwnsMany(o => o.LineItems, lineItem =>
    {
        lineItem.ToJson(); // Stored as JSON column
    });
});

EF Core 10 also provides ComplexCollection with ToJson for identity-free JSON collections. Check your provider's support before choosing a JSON model; do not apply ToTable and ToJson to the same collection.

Practical Example

Combining all three strategies in one entity:

public class Customer
{
    public Guid Id { get; private set; }
    public Email Email { get; private set; } = null!;        // Value conversion
    public Address? BillingAddress { get; private set; }   // Optional owned type
    public FullName Name { get; private set; } = null!;      // Complex type
}

public sealed record FullName(string First, string Last);

Configure those properties in OnModelCreating:

modelBuilder.Entity<Customer>(builder =>
{
    // Value conversion for single-property VO
    builder.Property(c => c.Email)
        .HasConversion<EmailConverter>();

    // Owned type for nullable multi-property VO
    builder.OwnsOne(c => c.BillingAddress, address =>
    {
        address.Property(a => a.Street).HasColumnName("billing_street");
        address.Property(a => a.City).HasColumnName("billing_city");
    });

    // Complex type for non-null multi-property VO
    builder.ComplexProperty(c => c.Name, name =>
    {
        name.Property(n => n.First).HasColumnName("first_name");
        name.Property(n => n.Last).HasColumnName("last_name");
    });
});

Summary

Value object persistence in EF Core:

1. Value conversions for single-property value objects - Email, PhoneNumber, strongly typed IDs
2. Owned types when you need separate-table mapping or compatibility with earlier EF Core releases
3. Complex types for grouped values without identity; nullability and JSON support depend on the EF Core version
4. OwnsMany for a collection table, or supported JSON mapping for a document-shaped collection
5. Apply globally with ConfigureConventions to avoid repetitive configuration

Choose the approach that matches your value object's structure and nullability requirements. Keeping those mappings outside the type preserves persistence ignorance without pretending the database has no constraints.
